Products: Preamplifiers: PR-X2


Model : PR-X2

Line Preamplifier

Features

PR-X2 is designed to match with all WAVAC Audio Lab's power amplifiers.

PR-X2 is also developed for the use of other power amplifiers of different brands.

Cosmetically PR-X2 has a charming slim body to entice audiophile.

Volume knobs are large and easy to operate from the human engineering point of view. This is also a part of uniqueness in design to appeal the eye of end-user.

For the convenience of the user, it has remote function of six input selections plus on-off power switch of PR-X2.(remote does not work for balance controls)

PR-X2 has separate power supply so that the body is made very thin.

Tubes are covered by the shielded case which enhance the value of product.

Like wise, CPU is covered by gold plated case for shielding.


Specification
Input terminal Digital level : 3ch
Analogue level : 3ch
Input sensitivity Digital level input : 2V
Analogue level input:500mV
Input impedance 100K ohms
Input sensitivity 1.0Vrms
Output terminal Pre-outx1ch : Rec-outx1ch
Output impedance Pre-out:10k Rec-out47k ohm
Output terminal Pre-outx1ch : Rec-outx1ch
Frequency range 20Hz-50KHz
S/N ratio 95dB
Power consumption 100 watts
Power supply 100,110,120,220,230,240
VAC 50-60Hz
(selected when shipped)
External dimensions 420Wx400Dx85H(mm)
Weight 3kg
(excluding power supply)
